Description
A complete commercial background music and paging system for hotel lobbies, reception areas, guest lounges, breakfast rooms and other small hospitality spaces.
This package combines a TEXONIC DXT60 60W Bluetooth amplifier with three CS75 two-way wall speakers for clear music, announcements and flexible wall-mounted sound coverage.
Designed for Hotels and Hospitality
The system is suitable for hospitality areas that need comfortable background music, simple staff operation and occasional voice paging.
- Hotel lobbies and reception areas
- Guest lounges and seating areas
- Breakfast and dining rooms
- Small bars and hospitality lounges
- Meeting and conference rooms
- Hallways and common areas
What’s Included
1 × TEXONIC DXT60 60W Mixer Amplifier
A compact commercial amplifier with Bluetooth streaming, USB/MP3 playback, FM radio, microphone inputs, AUX input and 70V or 8-ohm speaker output.
3 × TEXONIC CS75 Wall Speakers
Three 5-inch two-way commercial speakers with a separate tweeter, adjustable wall brackets and selectable 70V power taps for balanced music and clear voice reproduction.
Music and Paging Features
- Bluetooth streaming from compatible devices
- USB/MP3 music playback
- Built-in FM radio
- Microphone inputs for announcements
- AUX input for an external music source
- Individual input volume controls
- Bass, treble and master volume adjustment
Flexible Wall-Mount Installation
The CS75 speakers can be installed horizontally or vertically and aimed toward reception desks, seating areas, dining spaces or other guest areas.
Wall mounting is practical for concrete ceilings, decorative ceilings, open structures or finished spaces where ceiling speaker installation is not preferred.
Recommended 70V Configuration
Connect all three speakers in parallel using the DXT60 amplifier’s 70V and COM terminals. Keep the speaker-wire polarity consistent throughout the installation.
Recommended speaker setting: Set each CS75 speaker to the 15W/70V tap.
Three speakers at 15W create a total connected load of 45W, leaving 15W of amplifier headroom.
Important: Use either the 70V output or the 8-ohm output. Do not connect both speaker output types at the same time.
Speaker Placement
Position the three speakers evenly across the main listening area and direct them toward guests rather than reflective walls or glass. Final placement should consider the room layout, ceiling height, background-noise level and preferred volume.
Why Buy from AVTECK?
- Canadian commercial audio specialist
- Ships from our Barrie, Ontario warehouse
- Canadian technical and product support
- Free basic wiring diagram on request
- Support before and after your purchase
Warranty
TEXONIC DXT60 Amplifier: 2-Year Warranty
TEXONIC CS75 Wall Speakers: 3-Year Warranty
Need Help?
Send us your room dimensions, ceiling height, floor plan and intended hospitality area. We can help confirm whether this package is suitable and recommend wall speaker locations.
