Description
Four Speaker Positions for More Even Background Music
Designed for businesses where three speakers may not provide enough placement flexibility. This package combines a TEXONIC DXT60 60W Bluetooth mixer amplifier with 4 TEXONIC PZ50 pendant speakers to spread music across a longer, wider or more open commercial listening area.
Why Choose Four Pendant Speakers?
The advantage is not simply more volume. A fourth speaker gives you another sound position, helping reduce loud and quiet areas across the room.
Cover the Room with More Speaker Positions
Four pendant speakers can be positioned across the main listening area instead of asking two or three speakers to reach the entire room.
This is especially useful for rectangular cafés, wider retail floors, reception areas and open spaces where customers are spread across different parts of the room.
A Better Fit for These Room Layouts
Four speaker positions make it easier to cover seating, service and counter areas without making the speakers closest to customers too loud.
Space the speakers across displays, aisles and the checkout area for more consistent background music throughout the customer space.
Suitable for an open shared area where music needs to reach several seating, waiting or working positions from one audio system.
Simple Music & Paging from One Location
Staff can play everyday background music through Bluetooth, USB, SD card, FM radio or a connected external audio source.
The same amplifier also accepts compatible microphones for customer announcements or staff paging when required.
What's Included?
- 60W rated commercial output
- 70V / 100V speaker outputs
- Bluetooth playback
- USB / SD music playback
- Built-in FM radio
- AUX / external audio input
- Microphone inputs for paging
- 5" 2-way commercial pendant speaker
- 5" woofer + 1.5" tweeter
- 70V / 100V operation
- 2.5W / 5W / 10W selectable taps
- Approx. 2 m steel suspension cable
- Speaker lead included
- Black or white finish available
Black or White for Your Ceiling Design
Choose black for dark exposed ceilings, ductwork and industrial-style interiors, or white for brighter architectural spaces.
The speaker performance and available 70V/100V tap settings remain the same; the colour choice is primarily about how the system fits the room visually.
Plan Four Separate Sound Positions
The four pendant speakers should normally be spread across the main listening area instead of installed close together.
This is only a planning example. Actual speaker positions should follow the shape and use of the room rather than forcing every installation into the same layout.
Best Considered for Around 900–1,400 sq. ft.
This four-speaker package is a practical starting point for many small-to-medium commercial listening areas of approximately 900 to 1,400 sq. ft.
Which Package Size Makes Sense?
| Your Project | Recommendation | Why |
|---|---|---|
| Compact, simple room under about 900 sq. ft. | Compare 3 Speakers | A smaller room may not require four separate sound positions. |
| Approx. 900–1,400 sq. ft. open area | 4-Speaker Package | Four positions provide more placement flexibility across the room. |
| Long café or wider retail floor | 4 Speakers | Useful when customers are distributed across several parts of the room. |
| Large, noisy or substantially larger open space | Choose a Larger System | More speakers and/or more amplifier power may be required. |
| Separate rooms needing different volume or music | Choose Multi-Zone Audio | The DXT60 provides one shared audio program. |
Simple 70V Speaker Setup
A practical starting setting for this package is 10W per PZ50 pendant speaker.
The 40W connected speaker load stays within the DXT60's 60W rated output, leaving 20W of unused amplifier capacity.
For quieter background music, a lower speaker tap can be selected. Final settings should consider speaker height, room noise and the required listening level.
Everyday Music & Optional Paging
Phone / Tablet / Computer
MP3 Playback
Built-In Tuner
External Audio Source
Microphone Sold Separately
Plan the Suspension Points Before Ordering
Each PZ50 must hang from a suitable secure structural mounting point. Plan four useful speaker positions over the listening area rather than choosing positions only because they are convenient for mounting.
A recessed ceiling-speaker package may provide a cleaner installation.
Send Us the Room Shape, Not Just the Square Footage
A 1,200 sq. ft. long narrow café may need a different speaker layout than a 1,200 sq. ft. square showroom. Send AVTECK the basic room information and we can help confirm whether four pendant speakers are a sensible starting point.
Package Summary
| Package SKU | TXPP04-03 |
| Amplifier | 1 × TEXONIC DXT60 – 60W |
| Speakers | 4 × TEXONIC PZ50 5" 2-Way Pendant Speakers |
| Speaker Colour | Black or White |
| Speaker System | 70V / 100V Commercial Audio |
| Audio Zones | 1 Shared Audio Zone |
| Music Sources | Bluetooth / USB / SD / FM / AUX |
| Paging | Yes – compatible microphone sold separately |
| Planning Range | Approx. 900–1,400 sq. ft., depending on room conditions |
| Best Fit | Longer, wider or less-uniform open-ceiling commercial spaces |
| Speaker Cable | Main installation speaker cable sold separately |
Warranty
2-Year TEXONIC Warranty
3-Year TEXONIC Warranty
