Description
Commercial Open Ceiling Audio Package
10 Pendant Speaker Commercial Sound System
Professional 70V pendant speaker system with commercial amplifier designed for larger open ceiling restaurants, breweries, gyms, retail stores, cafés, warehouses, and modern business interiors.
Commercial mixer amplifier with 10 pendant speakers for distributed 70V audio coverage.
Open ceiling restaurants, cafés, fitness studios, breweries, retail stores, and warehouses.
Background music, microphone paging, announcements, and customer communication.
Commercial Audio Coverage for Larger Open Spaces
This 10 pendant speaker sound system is designed for larger commercial spaces where wider audio coverage is required. Pendant speakers suspend lower from exposed ceilings, helping improve sound distribution compared to standard ceiling-mounted speakers in high ceiling environments.
The system works well in larger cafés, restaurants, breweries, fitness studios, retail stores, showrooms, warehouses, and commercial spaces with exposed ceilings or industrial-style interiors.
Benefits of a Pendant Speaker System
Improved Audio Placement
Hanging speakers place sound closer to customers and staff for clearer coverage.
Better for Exposed Ceilings
A practical option where traditional ceiling speakers cannot be installed easily.
Modern Commercial Appearance
Pendant speakers complement industrial and modern commercial interiors.
Expanded Audio Coverage
Ten speakers help distribute music more evenly across larger business areas.
Commercial Amplifier Features
Bluetooth Streaming
Quickly play music from compatible Bluetooth devices without extra hardware.
USB & SD Media Player
Built-in MP3 playback support from USB drives and SD cards.
Commercial Paging Chime
Built-in chime helps create smoother business announcements and paging.
Voice Priority Function
Microphone announcements automatically lower background music volume.
Proper Amplifier and Speaker Matching
This package uses the 70V speaker output connection of the commercial amplifier. Each pendant speaker is configured at a 15W tap setting for balanced commercial audio coverage.
Total speaker load: 10 speakers × 15W = 150W system load.
The EX240D commercial amplifier provides 240W output power, leaving suitable amplifier headroom for stable operation, cleaner sound quality, and future expansion possibilities when compatible 70V speaker tap settings are used correctly.
System Specifications
| System Type | 10-speaker commercial pendant audio system |
| Amplifier Model | TEXONIC EX240D commercial mixer amplifier |
| Speaker Configuration | 10 commercial pendant speakers |
| Speaker Tap Setting | 15W per speaker |
| Total Speaker Load | 150W total load |
| Recommended Applications | Restaurants, cafés, gyms, retail stores, warehouses, and breweries |
| Audio Functions | Background music, microphone paging, and announcements |
Important 70V Connection Notice
The EX240D amplifier supports 8-ohm, 70V, and 100V speaker outputs. This package is designed for the 70V output only. Do not combine the 70V output with the 8-ohm or 100V terminals. Incorrect wiring may damage the amplifier.
Optional Wi-Fi Audio Streaming
For businesses playing music throughout the day, a Wi-Fi audio streamer can provide more stable app-controlled music playback.
Recommended Add-On Products
Need Help Planning a Commercial Pendant Speaker System?
Contact our team with your ceiling height, room size, and business type. We can help recommend the correct commercial audio layout, amplifier sizing, and speaker placement for your project.
