Description
Bring clear background music and paging to indoor or outdoor commercial spaces with a rugged pair of 6.5-inch surface-mount speakers designed for 70V, 100V and compatible 6-ohm audio systems.
The Russound AW70V6mk2 is a two-way indoor/outdoor speaker pair featuring polypropylene woofers, titanium-dome tweeters and selectable commercial audio transformers. Each speaker includes a weather-resistant rear tap selector, rustproof aluminum grille, adjustable mounting bracket and durable ported enclosure. Available in black or white, the pair is ideal for restaurants, retail stores, hotels, offices, patios, schools and distributed business-audio systems.
Russound AW70V6mk2 Surface-Mount Speaker Pair
The AW70V6mk2 package contains two matching passive speakers. Each enclosure combines a 6.5-inch woofer, 1-inch tweeter, 60-watt transformer, adjustable tap selector and mounting bracket.
The speakers can operate from a 70V or 100V commercial amplifier. A transformer-bypass position also allows each speaker to operate as a conventional 6-ohm loudspeaker with a compatible low-impedance amplifier.
Current model: AW70V6mk2
Speaker design: Two-way passive surface-mount speaker
Operating options: 70V, 100V or 6Ω
Available colours: Black or white
Package quantity: Two speakers
Two-Way Sound for Music and Paging
Each speaker uses a 6.5-inch injection-moulded polypropylene woofer to reproduce bass, vocals and midrange content. A separate 1-inch titanium-dome tweeter provides clear speech and high-frequency detail.
This two-way configuration is suitable for commercial background music, paging, recorded announcements and general voice communication. The ported enclosure supports fuller low-frequency performance than a similarly sized sealed cabinet.
Full-Range Commercial Audio Performance
The published frequency response is 55Hz–20kHz, providing useful coverage for vocals, instruments, announcements and everyday commercial music.
Frequency response: 55Hz–20kHz, ±3dB
Sensitivity: 87dB
Low-impedance power handling: Up to 100W per speaker
For high-impact bass or louder foreground music, consider adding a compatible subwoofer or using additional speakers to distribute the sound more evenly.
Recommended Commercial Applications
| Business Type | Typical Use |
|---|---|
| Restaurant or Café | Dining-room music, paging and outdoor patio sound |
| Retail Store or Showroom | Background music, customer announcements and promotions |
| Hotel or Hospitality Property | Lobby, lounge, pool area, patio and common-area audio |
| Office or Reception Area | Music, presentations and general staff paging |
| School or Community Facility | Program audio, announcements and multipurpose-room sound |
| Recreation or Fitness Facility | Indoor or outdoor program music and voice reinforcement |
| Residential Outdoor Audio | Patios, decks, pool areas and distributed home audio |
Selectable 70V and 100V Transformer Taps
A weather-resistant selector on the rear of each speaker allows the installer to choose a transformer tap that matches the amplifier output and required sound level.
| Operating Mode | Available Settings Per Speaker |
|---|---|
| 70V | 7.5W / 15W / 30W / 60W |
| 100V | 15W / 30W / 60W |
| Transformer Bypass | 6Ω low-impedance operation |
Use only the tap settings identified for the amplifier’s actual speaker-line voltage.
The 7.5W setting is for 70V operation only. The lowest published 100V setting is 15W.
Choosing a Tap Setting
| Tap | General Application |
|---|---|
| 7.5W | Quiet indoor rooms and comfortable background music |
| 15W | Offices, retail stores and general commercial audio |
| 30W | Restaurants, patios and areas with moderate background noise |
| 60W | Larger or noisier areas requiring higher speaker output |
These examples are general starting points. Final tap selection depends on the speaker quantity, mounting height, listening distance, room acoustics, outdoor noise and required sound level.
Calculate the Amplifier Load for the Pair
The package contains two speakers. When both speakers use the same tap, multiply the tap setting by two.
| Pair Configuration | Total Load | Practical Amplifier Size |
|---|---|---|
| 2 speakers at 7.5W | 15W | 30W or higher |
| 2 speakers at 15W | 30W | 60W or higher |
| 2 speakers at 30W | 60W | 120W or higher |
| 2 speakers at 60W | 120W | 150W or higher |
| 2 pairs at 15W per speaker | 60W | 120W or higher |
| 4 pairs at 15W per speaker | 120W | 150W or higher |
Maintain Amplifier Headroom
For reliable commercial operation, avoid loading the amplifier to its full rated output. Keeping approximately 20% reserve capacity is a practical system-planning target.
| Amplifier Rating | Recommended Maximum Tap Load |
|---|---|
| 30W | Approximately 24W |
| 60W | Approximately 48W |
| 120W | Approximately 96W |
| 150W | Approximately 120W |
| 240W | Approximately 192W |
6Ω Transformer-Bypass Operation
Each speaker can operate as a conventional 6-ohm passive speaker when the rear selector is set to the bypass position.
Russound recommends approximately 10–100W RMS of amplifier power per speaker in low-impedance mode. One speaker presents a nominal 6-ohm load.
| Low-Impedance Connection | Nominal Load |
|---|---|
| One speaker on one amplifier channel | 6Ω |
| Two speakers connected in parallel | 3Ω |
One speaker per stereo amplifier channel is normally the safest low-impedance arrangement. Do not connect two speakers in parallel unless the amplifier is specifically rated for stable 3-ohm operation. Never connect the 6Ω bypass setting to a 70V or 100V amplifier terminal.
Parallel Wiring for 70V and 100V Systems
Multiple AW70V6mk2 speakers in a commercial distributed system connect electrically in parallel. The speaker cable can run from the amplifier to the first speaker and continue to additional speakers.
- Connect every speaker to the same 70V or 100V output.
- Maintain consistent positive and common polarity.
- Select the correct transformer tap on each speaker.
- Add all selected tap values to calculate the amplifier load.
- The gold-plated terminals accept speaker cable up to 12 AWG.
- Disconnect amplifier power before wiring or changing tap settings.
Important Connection Warning
Select the correct 70V, 100V or 6Ω position before switching on the amplifier.
Do not use the 7.5W tap with a 100V amplifier output.
Do not connect the 6Ω bypass setting to a 70V or 100V output.
Do not mix constant-voltage and low-impedance amplifier outputs on the same speaker line.
Power down and disconnect the amplifier before adjusting the rear selector or speaker wiring.
Indoor and Outdoor Construction
The AW70V6mk2 is designed for indoor and outdoor installations. Its durable cabinet, weather-resistant tap selector, rustproof powder-coated aluminum grille and aluminum mounting bracket are suited to changing outdoor conditions.
Typical outdoor locations include patios, decks, pool areas, covered entrances and hospitality spaces. Install each speaker with suitable cable, weather protection and structural support for the location.
Russound identifies the product for outdoor use but does not publish an IP number in the reviewed specifications. Do not advertise a specific IP rating unless it is confirmed on the current product documentation.
Flexible One-Handed Mounting System
The rugged mounting bracket supports vertical or horizontal wall installation and is designed to simplify positioning while the speaker is secured.
The cabinet’s narrow rear taper makes it easier to install near corners. Standard U-bolts can be used for appropriate pole installations, and dual 1/4-inch brass inserts allow compatible third-party mounts or secondary security attachments.
- Vertical wall mounting
- Horizontal wall mounting
- Corner installation
- Under-eave mounting
- Compatible pole mounting
- Compatible third-party mounting systems
Black and White Colour Options
| Variant | Colour | UPC / GTIN |
|---|---|---|
| AW70V6MK2 WHITE | White | 612934853883 |
| AW70V6MK2 BLACK | Black | 612934853890 |
Technical Specifications
| Brand | Russound |
| Current Model | AW70V6mk2 |
| Product Type | Two-way passive indoor/outdoor surface-mount speaker pair |
| Woofer | 6.5-inch injection-moulded polypropylene |
| Tweeter | 1-inch titanium dome |
| Enclosure Design | Two-way ported cabinet |
| Frequency Response | 55Hz–20kHz, ±3dB |
| Sensitivity | 87dB |
| Transformer Rating | 60W |
| 70V Taps | 7.5W / 15W / 30W / 60W |
| 100V Taps | 15W / 30W / 60W |
| Low-Impedance Mode | 6Ω transformer bypass |
| Low-Impedance Power Handling | Up to 100W per speaker |
| Recommended Amplifier Power | Approximately 10–100W RMS per speaker in 6Ω mode |
| Speaker Connections | Gold-plated screw-down terminals |
| Maximum Cable Size | Up to 12 AWG |
| Grille | Powder-coated rustproof aluminum |
| Mounting Bracket | Rugged aluminum one-handed mounting bracket |
| Mounting Inserts | Dual 1/4-inch brass inserts |
| Dimensions Per Speaker | 13 H × 8.75 W × 8.25 D in |
| Metric Dimensions | Approximately 33 × 22.2 × 21cm per speaker |
| Weight Per Speaker | Approximately 9 lb / 4.1kg |
| Available Colours | Black or white |
| Package Quantity | Two speakers |
| Recommended Use | Commercial background music, paging and indoor/outdoor audio |
What’s Included
- 2 × Russound AW70V6mk2 surface-mount speakers
- 2 × adjustable mounting brackets
- Mounting hardware supplied with the speaker package
- AW70V6mk2 installation-manual access
Two-Year Russound Warranty
The Russound AW70V6mk2 is covered by a limited two-year manufacturer’s warranty, subject to the current Russound warranty terms and proof of purchase.
Frequently Asked Questions
Are the AW70V6mk2 speakers sold individually or as a pair?
They are sold as a pair. One product package contains two speakers and two mounting brackets.
Can these speakers connect to a 70V amplifier?
Yes. Each speaker provides 7.5W, 15W, 30W and 60W taps for a compatible 70V amplifier.
Can they connect to a 100V amplifier?
Yes. Each speaker provides 15W, 30W and 60W settings for compatible 100V operation.
What is the amplifier load for the pair at 30W?
Two speakers at 30W create a total 60W transformer load. A 120W commercial amplifier provides practical operating headroom.
Can the speakers connect to a regular amplifier?
Yes. Set each rear selector to the 6Ω bypass position and use a compatible low-impedance amplifier. One speaker per stereo channel is generally recommended.
Can both 6-ohm speakers connect to one amplifier channel?
Two 6-ohm speakers connected in parallel create approximately a 3-ohm load. Use this arrangement only when the amplifier is specifically rated for stable 3-ohm operation.
Are these speakers suitable for outdoor use?
Yes. The AW70V6mk2 is designed for indoor and outdoor installations and includes weather-resistant controls, an aluminum grille and a durable enclosure.
Do the speakers have a published IP rating?
A specific IP number is not listed in the reviewed specifications. Follow the current Russound installation instructions for outdoor placement.
Can the speakers be mounted horizontally?
Yes. The brackets support vertical or horizontal installation, and the Russound grille logo can be rotated to match the speaker orientation.
Is this the recalled AW70V6 model?
No. This listing is for the replacement AW70V6mk2 model. Confirm that the product label states AW70V6mk2 before installation.
Need Help Planning the Speaker System?
Send AVTECK the room or outdoor-area dimensions, mounting height, speaker quantity, amplifier model and required listening level. We can help calculate the transformer load and recommend a practical commercial audio configuration.
