Description
3-Port HDMI Switch
The 3- Port HDMI switch allows 3 HDMI ports to be switched to a single display terminal via remote control or buttons on unit. The switcher can be also placed at the end of a long HDMI cable to regenerate the HDMI signal. This HDMI Switch supports video formats including 720p, 1080i , 1080p. No need to install drivers, it's portable, flexible, you simply need to plug and play. If power supply is insufficient, you can also connect the external power adapter.
SPECIFICATIONS
- HDMI version: HDMI 1.4a
- HDMI resolution: 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
- Support video color format: 8/10/12 bit deep color
- Support audio format: DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD
- Max bandwidth: 225MHz
- Max baud rate: 2.25Gbps
- Input cable distance: ≤15m AWG26 HDMI standard cable
- Output cable distance: ≤25m AWG26 HDMI standard cable
- Operating Humidity range: 5 to 90%RH (No Condensation)
- Dimension (L x W x H): 77x56x15 (mm)
- Weight: 40g
- Max working current: 150mA
- Operating Temperature range: (-15 to +55℃)
Operating and Connecting
- Connect 3 HDMI signal sources into HDMI switch input with 3 HDMI cables
- Connect 1 HDMI display source into HDMI switch output with 1 HDMI cable
INCLUDED
- Instruction Manual
- Remote control
