Description
TOA SC-630TU 30W Paging Horn Speaker for Outdoor Use
Weatherproof Paging Horn Speaker with UL Certification
The TOA SC-630TU Paging Horn Speaker is a powerful, compact solution designed for public address announcements, voice paging, and tone signaling in outdoor environments. Certified to UL 1480 UUMW and ULC-S541 standards, this 30W speaker is ideal for fire alarm signaling and other critical applications. Its double re-entrant horn and compression driver provide high intelligibility, while the weatherproof construction ensures durability in harsh environmental conditions. The speaker is IP65 rated for dust and moisture resistance and operates within a wide temperature range of -40°F to 151°F. The SC-630TU also features a built-in transformer with an impedance selector for 25V and 70V line applications.
Specifications:
- Rated Input: 30W
- Rated Impedance:
- 70V line: 170Ω (30W), 330Ω (15W), 650Ω (7.5W)
- 25V line: 21Ω (30W), 42Ω (15W), 170Ω (3.9W), 330Ω (2.1W), 650Ω (1.1W)
- Sound Pressure Level: 113 dB (1W, 1m at 500 Hz to 2.5 kHz peak level)
- Frequency Response: 250 Hz – 10 kHz
- Weather Resistance: IP65
- Operating Temperature: -40°F to 151°F
- Certifications: UL 1480 UUMW, ULC-S541
- Dimensions: 285 (W) x 227 (H) x 277 (D) mm (11.22" x 8.94" x 10.91")
- Weight: 2 kg (4.41 lbs)
- Finish: Powder-coated aluminum horn flare, ABS resin reflector horn, and stainless steel bracket.
This product is built for reliability and exceptional performance, making it perfect for both commercial and industrial use.
